Handheld Marking Machine
Product main features:
Automatic programming: marking is rich in content, can play in English, Chinese characters, numbers, graphics, logo etc.
Printing: printing effect is colorless and dent (dot, line 2 marking mode) permanent marker.
The needle system: automatic needle system, can quickly and accurately the marking content moved to the corresponding position.
Fonts: multiple fonts available, and you can edit the new font, with scanning camera.
Analog display: without labeling, direct observation of marked effect on screen, what you see is what you get.
Storage function: automatic collating sequence, marking time, quantity, content, automatic storage for statistics.
Setting: automatic collating sequence, marking time, quantity and content are automatically stored for statistical.
The stability of the system: the system is stable, can work continuously for 24 hours.
Marking requirements: special alloy print needle, mark clear, consistent with the Ministry of Public Security announced vehicle marking requirements.
Small size: marking machine specialized controller, light weight, small volume, easy to carry out.
Magnet: using magnet adsorption methods of marking, easy to use.
A variety of font: font library with multiple fonts available, you can edit the VIN code and other new font.
The main performance parameters of products:
|
Operating system
|
Windows CE
|
|
Print size
|
100 x 30mm, 120 x 30mm, 160 x 30mm, 180 x 30mm
|
|
Minimum character
|
1 × 1mm (word size can be changed by software arbitrary)
|
|
Print the contents
|
Chinese, English, numbers, graphics, serial number, VIN code etc.
|
|
Printing speed
|
3-12 characters per second
|
|
Print depth
|
0.01-2mm (according to the material constant)
|
|
Print mode
|
manual input, automatic printing
|
|
Printing
|
colorless dent
|
|
The steel hardness
|
HRC95
|
|
Print material
|
all kinds of metal (HRC65 ° hardness), all kinds of hard materials
|
|
Editor
|
software provides self editor, handwriting input, the plane circular, fan-shaped and circular distribution
|
|
Graphics conversion
|
software provides AutoCAD, CorelDRAW, CAXA graphics file conversion mode
|
|
Accuracy
|
the self-lubricating type precision linear slide rail, work for five consecutive years working error less than 0.01mm
|
|
Dimensions
|
180 x 150 x 80mm (length, width, height)
|
|
Weight
|
1-3.6Kg
|
